Dual wavelength LS MM 850/1300nm (SC)

Product code	16305004
Sales unit	Pcs
ETIM-Class	EC000305

Compare

Product specifications

SLS-21 adopts the latest technology to display the output power value and wavelength of the laser source directly in the LCD.

●Applicable on singlemode/multimode fibers

●Unique Output Power Display

●CW/MOD tones output

●Quick response, no warm-up

●Interchangeable connectors: FC/SC/ST

●9V alkaline battery/AC adapter

●Power saving: Auto-off setting

●Pocketsize, lightweight and damp-dust-shock proof

●CE, FCC, FDA certificates

Length	235 mm
Height	80 mm
Width	160 mm
Weight	30 g

Documents

Data Sheets

16305004-EN-FDV.pdf

Technical Specifications - Test & Measurement Equipment

Fibre Type	Multimode
Calibrated Wavelengths	850nm, 1300nm
Power Range	≥-7
MOD Identification
Connector Type	SC/UPC
Output Connector	SC
Battery Tye	9V Alkaline Battery
Battery Life	20 h
Power Save Feature	Yes
Light Source	850nm, 1300nm
Laser Type	FP, LD

Physical Specifications - Test & Measurement Equipment

Weight	300 g
Length	145 mm
Width	75 mm
Height	25 mm
Relative Humidity	95 %
Temperature ranges for Operation	-20°c to 50°c
Temperature ranges for transport and storage	-40°c to 70°c
