Reinforced Plastic (Fiberglass)

2F Blown fiber EPSU SM G657A1 Yellow HDPE 1,2mm 6km/pan, S12

5042434

2F SM G657A1 EPSU air blown optical fibre is typically used in micro duct installation applications. ABF can utilize in existing and new duct systems more effectively by accommodating more fibres in given subduct network. The fiber units is suitable for air-blown installation. Cable parameters such as cable diameter, stiffness and sheath friction is optimized for best installation performance. The expected service life in normal use exceeds 30 years.

4F Blown fiber EPSU SM G657A1 Yellow HDPE 1,2mm 6km/pan, S12

5042435

4F SM G657A1 EPSU air blown optical fibre is typically used in micro duct installation applications. ABF can utilize in existing and new duct systems more effectively by accommodating more fibres in given subduct network. The fiber units is suitable for air-blown installation. Cable parameters such as cable diameter, stiffness and sheath friction is optimized for best installation performance. The expected service life in normal use exceeds 30 years.

8F Blown fiber EPSU SM G657A1 Yellow HDPE 1,4mm 4km/pan, S12

5042436

8F SM G657A1 EPSU air blown optical fibre is typically used in micro duct installation applications. ABF can utilize in existing and new duct systems more effectively by accommodating more fibres in given subduct network. The fiber units is suitable for air-blown installation. Cable parameters such as cable diameter, stiffness and sheath friction is optimized for best installation performance. The expected service life in normal use exceeds 30 years.

12F Blown fiber EPSU SM G657A1 Yellow HDPE 1,6mm 4km/pan, TIA/S12

5042437

12F SM G657A1 EPSU air blown optical fibre is typically used in micro duct installation applications. ABF can utilize in existing and new duct systems more effectively by accommodating more fibres in given subduct network. The fiber units is suitable for air-blown installation. Cable parameters such as cable diameter, stiffness and sheath friction is optimized for best installation performance. The expected service life in normal use exceeds 30 years.

2F SM G657A1 CLT LSZH Green E-glasyarn 2100m/dr

4967787

2F SM G657A1 Multi purpose cable used for both indoor installation and outdoor installation in ducts applications by pulling. Cable parameters such as cable flexibility, diameter and higher safety levels for fire and dangerous substances makes it optimized for safe and effective indoor installation as well as for outdoor installtion in ducts. The cable is based on a central loose tube construction (CLT). The expected service life in normal use exceeds 30 years.

4F SM G657A1 CLT LSZH Green E-glasyarn 2100m/dr

4967797

4F SM G657A1 Multi purpose cable used for both indoor installation and outdoor installation in ducts applications by pulling. Cable parameters such as cable flexibility, diameter and higher safety levels for fire and dangerous substances makes it optimized for safe and effective indoor installation as well as for outdoor installtion in ducts. The cable is based on a central loose tube construction (CLT). The expected service life in normal use exceeds 30 years.

8F SM G657A1 CLT LSZH Green E-glasyarn 2100m/dr

4967807

8F SM G657A1 Multi purpose cable used for both indoor installation and outdoor installation in ducts applications by pulling. Cable parameters such as cable flexibility, diameter and higher safety levels for fire and dangerous substances makes it optimized for safe and effective indoor installation as well as for outdoor installtion in ducts. The cable is based on a central loose tube construction (CLT). The expected service life in normal use exceeds 30 years.

12F SM G657A1 CLT LSZH Green E-glasyarn 2100m/dr

4967877

12F SM G657A1 Multi purpose cable used for both indoor installation and outdoor installation in ducts applications by pulling. Cable parameters such as cable flexibility, diameter and higher safety levels for fire and dangerous substances makes it optimized for safe and effective indoor installation as well as for outdoor installtion in ducts. The cable is based on a central loose tube construction (CLT). The expected service life in normal use exceeds 30 years.

24F SM G657A1 CLT LSZH Green E-glasyarn 2100m/dr

4967887

24F SM G657A1 Multi purpose cable used for both indoor installation and outdoor installation in ducts applications by pulling. Cable parameters such as cable flexibility, diameter and higher safety levels for fire and dangerous substances makes it optimized for safe and effective indoor installation as well as for outdoor installtion in ducts. The cable is based on a central loose tube construction (CLT). The expected service life in normal use exceeds 30 years.

48F SM G652D MLT LSZH Green E-glasyarn 2100m/dr

4967907

48F SM G652D Multi purpose cable used for both indoor installation and outdoor installation in ducts applications by pulling. Cable parameters such as cable flexibility, diameter and higher safety levels for fire and dangerous substances makes it optimized for safe and effective indoor installation as well as for outdoor installtion in ducts. The cable is based on a multi loose tube construction (MLT). The expected service life in normal use exceeds 30 years.

96F SM G652D MLT LSZH Green E-glasyarn 2100m/dr

4967977

96F SM G652D Multi purpose cable used for both indoor installation and outdoor installation in ducts applications by pulling. Cable parameters such as cable flexibility, diameter and higher safety levels for fire and dangerous substances makes it optimized for safe and effective indoor installation as well as for outdoor installtion in ducts. The cable is based on a multi loose tube construction (MLT). The expected service life in normal use exceeds 30 years.

2F SM G657A1 Bk HDPE UT Flat Self-supporting, 4000m/dr

2F SM G657A1 Flat ADSS cable designed for a maximum of 70m span lengths (distance between poles) under ice and wind conditions according to NESC heavy. The cable is based on a central loose tube construction (CLT). Two strain reliefs made of fiberglass-reinforced plastic (FRP) are embedded in the cable sheath for best tensile strength performance.

4F ADSS 7,7mm G657A1 Flat 9/125 UT Black HDPE 4,0km/dr 4F ADSS 7,7mm G657A1 Flat

4F SM G657A1 Flat ADSS cable designed for a maximum of 70m span lengths (distance between poles) under ice and wind conditions according to NESC heavy. The cable is based on a central loose tube construction (CLT). Two strain reliefs made of fiberglass-reinforced plastic (FRP) are embedded in the cable sheath for best tensile strength performance.

12F SM G657A1 Bk HDPE UT Flat Self-supporting, 4000m/dr

12F SM G657A1 Flat ADSS cable designed for a maximum of 70m span lengths (distance between poles) under ice and wind conditions according to NESC heavy. The cable is based on a central loose tube construction (CLT). Two strain reliefs made of fiberglass-reinforced plastic (FRP) are embedded in the cable sheath for best tensile strength performance.

2F SM G657A1 Microcable CLT Orange PBT OD 2,0mm 2100m/dr

5041624

2F SM G657A1 Micro cable typically used in outdoor microduct installation applications. The cables are suitable for air-blown installation. Cable parameters such as cable diameter, stiffness and sheath friction are optimized for best installation performance. The cables are based on a central loose tube construction (CLT).

4F SM G657A1 Microcable CLT Orange PBT OD 2,0mm 2100m/dr

5041625

Micro cables typically used in outdoor microduct installation applications. The cables are suitable for air-blown installation. Cable parameters such as cable diameter, stiffness and sheath friction are optimized for best installation performance. The cables are based on a central loose tube construction (CLT).

2F SM G657A1 Microcable CLT Black HDPE OD 3,7mm, 4km/dr

4985727

2F SM G657A1 Micro cable typically used in outdoor microduct installation applications. The cables are suitable for air-blown installation. Cable parameters such as cable diameter, stiffness and sheath friction are optimized for best installation performance. The cables are based on a central loose tube construction (CLT). Two strain reliefs made of fiberglass-reinforced plastic (FRP) are embedded in the cable sheath for best tensile strength and blowing performance.

4F SM G657A1 Microcable CLT Black HDPE OD 3,7mm, 4km/dr

4985737

4F SM G657A1 Micro cable typically used in outdoor microduct installation applications. The cables are suitable for air-blown installation. Cable parameters such as cable diameter, stiffness and sheath friction are optimized for best installation performance. The cables are based on a central loose tube construction (CLT). Two strain reliefs made of fiberglass-reinforced plastic (FRP) are embedded in the cable sheath for best tensile strength and blowing performance.

12F SM G657A1 Microcable CLT Black HDPE OD 3,7mm, 4km/drum

4985757

12F SM G657A1 Micro cable typically used in outdoor microduct installation applications. The cables are suitable for air-blown installation. Cable parameters such as cable diameter, stiffness and sheath friction are optimized for best installation performance. The cables are based on a central loose tube construction (CLT). Two strain reliefs made of fiberglass-reinforced plastic (FRP) are embedded in the cable sheath for best tensile strength and blowing performance.

12F G657A1 UT CST armored 10kN Black HDPE OD 9,9mm 4000m/dr

87405012

12F G657A1 armored cables designed for direct burial installation and has full rodent protection. It attains its mechanical robustness and functional performance through its corrugated steel tape (CST) reinforcement. Needs no further protection at underground installations. The cable is based on a central loose tube construction (CLT).

Download Data sheet
